描述
FT-X2-TLP781是北億纖通研發的一款小型貼片的光耦產品，適用于表面貼片組裝。FT-X2-TLP781由砷化鎵紅外發光二極管與帶基極-發射極電阻的、優化了開關速度和溫度特性的達林頓光電晶體管組成的高壓光電耦合器。
特性
? 集電極?發射極 電壓: 300 V (Min.)
? 電流傳輸比 1000%(Min.)
? 高隔離電壓: 3750Vrms (min.)
? UL 認證（NO.:E497745）
? 符合 EU REACH 和 RoHS
? CQC 認證（NO:CQC20001238665）
應用領域
? 可編程控制器
? 直流輸出模塊
? 遠程通訊等
?
?
?
?
?
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
