產品特點
速度:tr≤50ns;tf≤20ns
隔離電壓:1000V
集電極開路輸出
TTL/LSTTL/CMOS電平兼容
產品應用
設備輸入/輸出隔離
計算機接口電路
微處理器系統接口
開關電源
A/D、D/A轉換電路
國產軍品光耦：高速集電極開路輸出型有兩個系列：1，最大工作電壓7V，最大工作電流25mA，最大傳輸速率10Mbit/s；2，最大工作電壓15V，最大工作電流12mA，最大傳輸速率5Mbit/s；都有 1~32路可選,產品海量交付給 華為、中興、國防、軍工、航空、航天、兵器、艦船、雷達、電子、核工業、核武器、軍事、電力、鐵路、醫療、交通、通信、電信、移動、聯通、政府、國防科技工業系統內大專院校及科研院所軍品光耦
?
?
?
?
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
