產品特點
電源電壓:2V~50V
隔離電壓:1000V
集電極開路
靜電等級:1000V
產品應用
視頻信號隔離
電機驅動電路
實時控制電路
開關型電源中反饋元件
替代脈沖變壓器
國產軍品兩端達林頓輸出型光耦是北億纖通研發(fā)生產的一款國產軍品光耦，分為兩類：一類為輸出兩端口，最大工作電壓50V，傳輸比>2000%；一類為輸出三端口，最大工作電壓18V，傳輸比>500%；都有 1~32路可選
?
?
?
?
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
