產品特點
高電流傳輸比:1800%(典型值)
隔離電壓:1000V
集電極開路反相輸出
低電流驅動:0.5mA
TTL/ LSTTL/CMOS等電路兼容
產品應用
軍事和空間技術
微處理系統接口
電流回路接收器
系統測試設備隔離
程序控制中輸入/輸出隔離
國產軍品三端達林頓輸出型光耦是北億纖通研發生產的一款國產軍品光耦，分為兩類：一類為輸出兩端口，最大工作電壓50V，傳輸比>2000%；一類為輸出三端口，最大工作電壓18V，傳輸比>500%；都有 1~32路可選
?
?
?
?
Important Notice
Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by F-tone Networks before they become applicable to any particular order or contract. In accordance with the F-tone Networks policy of continuous improvement specifications may change without notice.
The publication of information in this data sheet does not imply freedom from patent or other protective rights of F-tone Networks or others. Further details are available from any F-tone Networks sales representative.
